Aurora 4K60 1G Unified Communication AVoIP Transceiver, 1TB SSD
This product is no longer available.
SKU:
VPX-UC1-ULTRA-1TB
Brand:
Aurora Multimedia
Days
:
Hours
:
Mins
:
Secs
Features
- Configure as Encoder or Decoder
- Zero Frame Latency (1.78ms)
- 4K60 4:4:4 UHD 120m over 1G CAT 5e
- HDMI 2.0b, HDCP 2.2
- HDR10, HDR10+, Dolby Vision
- LPCM up to 12-channels, Dolby Digital Plus, Dolby TrueHD DTS HD Master Audio & ATMOS
- 12 bits color depth processing, 16bits OSD
- Enterprise Security (AES 256, 802.1x, HTTPS, & SSH)
- Scaling, Seamless Switching & Video Wall with Rotation
- MJPEG Preview up to 720p30
- 2.5G LAN PoE+ and 1G SFP for Fiber or 2nd RJ-45
- 2 HDMI Outputs, 1 HDMI Input
- Line In/Out Stereo
- RS-232 Serial Port and IR (In/Out)
- Channel Mapping with On-Screen Preview
- Integrated Web Server for Configuration
- USB 2.0 Ports for Cameras, HID Devices, Mass Storage, etc.
- Dante® 2/8 Ch Audio License Options & Dante Controller
- Rack and Under Table Mounting
Processor
- 8 Core 2.4GHz Processor • Android 12 OS
- 1TB SSD Option
- 3 USB 3.1
- Dual 8K60 HDMI Outputs • ReAX Control Engine
- Works with Zoom®, Teams®, WebEx®, Microsoft® 365, and any other Android App.
AI Option
- 6TOP NPU
- Gender, Age, & Emotion Prediction
- People Counting
| Model Name | VPX-UC1-ULTRA |
| CPU | |
| Processor | Android 12, 8-Core 64-bit ARM Processor 2.4GHz with 6TOP NPU |
| Memory | 32GB FLASH with 4GB RAM & (Up to 1TB SSD Expansion) |
| USB Ports | 2 USB 3.1 Type A, 1 Type-C |
| HDMI Outputs | 2 (HDMI 2.1, HDCP 2.3) Up to 8K60 |
| AVoIP | |
| Compression | Mimix™ 13:1 |
| Latency | 0 Frames (1.78ms) |
| HDMI Inputs | 1 (HDMI 2.0b, HDCP 2.2) |
| Encryption | AES 256 |
| Audio Analog | Stereo Line In/Out (3.5mm TRS) |
| 1G Ethernet | RJ-45 and SFP |
| LAN | RJ-45 10/100/1000M PoE |
| Video Bandwidth | 600MHz (Up to 4K2K 4:4:4 @ 60Hz) |
| Audio Support | Up to 12 Channels |
| Video Stream Bandwidth | 10Mbps – 800Mbps (4K60 4:4:4) |
| USB Bandwidth | 200Mbps (Camera), 160Mbps (HID/Mass Storage Devices) |
| RS-232 | Up to 115k Baud (3.5mm TRS) |
| IR | Bi-Directional (3.5mm TRS) |
| USB Connector | 1 USB 2.0 Type C, 2 USB 2.0 Type A |
| Options | Dante® 2Ch/8Ch |
| Interface | IR or Keyboard via OSD, Web Server |
| Mechanical | |
| Housing | Black Aluminum Enclosure |
| Dimensions (L x W x H) | 7” x 7.44” x 1.094” (17.7cm x 18.9cm x 2.75cm) |
| Weight | .453kg [1lbs] |
| Mounting | Optional: Rack Mount Vertical, Rack Mount Horizontal, Under Table Mount |
| Power Supply | 48v DC (2 Pin Euro) or PoE (LAN) |
| Power Consumption | 8 Watts, up to 12.9 Watts with USB |
| Operation Temperature | 0~40o C [32~104o F] |
| Storage Temperature | -20~60o C [-4~140o F] |
| Relative Humidity | 20~90% RH [No Condensation] |
| Package Contents | 1x VPX-UC1-ULTRA, 2x Mounting Ears |
About
The VPX-UC1 Ultra provides the most advanced 1G IP Streaming Unified Communications solutions on the market utilizing Aurora’s new Mimix™ CODEC technology. Mimix™ compression allows for near perfect reproduction of video and graphic images at resolutions up to 4K60 4:4:4 over 1G networks. It has zero frame (1.78ms) latency and seamless switching for fast lag free content. The combined 8 Core 12 Android Processor allows any Android application to be run and combined with the streaming content as a source. Perfect for UC and Digital Signage applications, the VPX-UC1 Ultra sets a new standard in price and performance.
