Aurora ReAX control processor with Ethernet & WiFi, and HDMI out for BYO touch monitor or digital signage and media playback

Aurora ReAX control processor with Ethernet & WiFi, and HDMI out for BYO touch monitor or digital signage and media playback

This product is no longer available.

SKU: RXM-1

Brand: Aurora Multimedia

Description

About

The RXM-1 is a ReAX controller with an HDMI output for digital signage and media playback applications. Using ReAX Core Studio software, users can schedule media playback, create powerful control interfaces, interactive kiosk applications, and more.

Product Features

Features

Powerful ReAX control system
Digital signage capable
Media playback engine
Interactive kiosk presentation solution
Add-on AI camera option for demographic prediction and logging
Completely customizable user interfaces

Technical Specifications

Hardware & OS

CPU	RK3399 hexa-core processor
RAM	4GB DDR3
ROM	32GB eMMC Flash
OS	Android 9

Video/Audio

Video Output	HDMI 2.0 output
Audio Output	Line out

Communication

Bluetooth	EDR 4.0
WiFi	802.11 b/g/n 2.4GHz and 5GHz
Ethernet	10/100/1000 LAN

General Information

I/O	12v DC Input, USB Type C, 3.5mm Audio Line L/R Out, HDMI 2.0 Output, SD Card Slot, SIM Card Slot (4G Option), USB 3.0, USB 2.0, 1G LAN PoE
Included in Box	RXM-1, WIFI Antenna, Mounting Ears
Power Consumption	11W
Power Input	12V 2A or PoE
Operating Environment - Temperature	Operating: 32°F to 100'F (0°C to 40°C); Storage: -4° F to 122°F (-20'C to 50°C)
Operating Environment - Humidity	Operating: 20%-80%; Storage· 10%-95%
Certification	CE, FCC, ROHS

Physical

RXM-1 Slze (WxHxD)

177mm x 104.2mm x 27.3mm (6.97” x 4.1” x 1.07”)
